Himiway D7 Pro
Himiway D7 Pro
Share
The Power of Wildest Dreams
The full suspension D7 Pro comes with a 1000 W Mid-drive Motor, 28 Mph Top Speed, 960 Wh Battery, 80 Miles Max Per Charge, 10-Speed Shimano Derailleur, Hydraulic Brakes, and a 400 lb. Payload Capacity.
Collapsible content
Size Chart
D7 Pro -- 5'3" ~ 6'5"
Cobra Pro -- 5'4" ~ 6'4"
-
A – total length 78.778.7 1
-
B – handlebar height42.7 2
-
C – handlebar length30.7 3
-
D – wheelbase52.6 4
-
E – wheel diameter28.7 5
-
F – minimum seat height20.9
-
G – maximum seat height30.4
-
H – chain stay length20
-
I – frame stack24.6 6
-
J – frame reach18.6
-
K – effective top tube length24.4 7
-
L – head tube length5.5 8
-
M – head angle63°
-
N – standover height30.7
- 1 - Cobra pro: 81.8
- 2 - Cobra pro: 44.5
- 3 - Cobra pro: 28
- 4 - Cobra pro: 52
- 5 - Cobra pro: 30.3
- 6 - Cobra pro: 25
- 7 - Cobra pro: 25
- 8 - Cobra pro: 5.9
Overview
1000 W
Mid-drive Motor
28 Mph
Top Speed *1
960 Wh
Samsung/LG Battery
80 Miles
Per Charge (maximum) *2
26x4.8
Super Fat Tire
10-Speed
Shimano Derailleur
Hydraulic
Brakes
400 lb.
Payload Capacity
1 - Reach speeds of up to 20 mph, No pedaling required.
2 - The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
Specifications
Frame
6061 Aluminum frame
Headset
Neco H383AE 28.6×44*56×30mm *9
Fork
KKE R150S coil spring fork compression/Rebound
adjustable 220mm travel 15*150mm thru axle *10
Shock
ROCKSHOX deluxe select+ 190*45mm *11
Front wheel
M9CF-150 12G*150*15mm 26'' 36h
Rear wheel
M9ZR-197 12G*197*12mm 26'' 36h
Tires
CST roly poly 26*4.8
Battery
Samsung/LG 48V 20Ah
Motor
BaFang M620 1000W mid-drive motor
Display
BaFang DP C18 LCD display
Throttle
Thumb throttle
Sensors
Torque sensor丨shifting sensor丨speed sensor丨brake sensor
Crankset
Crank arm: M620 (Fat) 170mm | Chain ring: 38T 104BCD narrow wide chainring *12
Cassette
Shimano cues CS-LG400-10 11-48T *13
Chain
KMC eglide 130L *14
Groupset
Shimano cues U6000 10 speed *15
Front brake
Tektro HD-E730 4-piston hydraulic brake
Rear brake
Tektro HD-E730 4-piston hydraulic brake
Rotors
F: TR203-17 R: TR180-17
9 - Cobra Pro: Neco H383AEM 28.6×44*56×39.8mm
10 - Cobra Pro:DASH-AIR-20 inverted fork 120mm lockout & rebound adjustable
11 - Cobra Pro: DNM A0-38RC Rear Shock 190*45mm
12 - Cobra Pro: Crank arm: M620 (Fat) 170mm | Chain ring: 44T BCD130
13 - Cobra Pro: Shimano CS-HG500-10 11-34T
14 - Cobra Pro: E10S-EPT 124L
15 - Cobra Pro: Shiminao deore M6000 10 speed
Components
Stem
3D forged alloy Ext:50mm
Handlebar
Promax HB-3188DB -W780 *16
Seatpost
Exa speed-up 30.9*500mm 150mm travel *17
Saddle
Selle royal vivo
Pedal
Wellgo B087B
Lights
48V LED light
Kickstand
Heavy-duty aluminum kickstand
16 - Cobra Pro: MTB-AL330BTF0V 700*22.2*31.8
17 - Cobra Pro: Promax SP-C212(ISO-M) 30.9*350mm
Other
Range
60-80 miles
Controller
48V/30A
Charger
US standard 3.0 A smart charger
Rider height
5′3″ ~ 6′5″
Weight
88.6 lb. (with battery)
Max. system weight
400 lb.
